Features

• Lowest activation in industry with 0.2 GPM turn on flow
• Active energy management with power modulating controls
• Microprocessor temperature control with digital display for thermostatic accuracy
• Field adjustable set point range between 70-180 F. Factory set at 120 F (3.5kW and below set at 105 F). Special
• settings of higher or lower range available based on options
• Silent Operation (except for SPEX0122240T)
• Mounts in any orientation
• Flow meter activates heater only on demand (no standby heat loss)
• Install unit at point-of-use to eliminate long pipe runs
• Eliminate costly mixing valve
• Compact size fits almost anywhere for flexible installation; suitable for ADA compliant facilitiesApplications:
  • Lavatory sinks
  • Multi lav configurations ideal for sensor or metering faucets(ML option - 110°F max.)
  • Emergency eye wash fountains (EE option - 90°F max.)

  Specifications:

  • Max Pressure (PSI): 150
  • Min Pressure (PSI): 30
  • Temperature Range (F): 70°F - 180°F
  • Voltage: 240v
  • Amps (240V): 40
  • Kilowatts (KW): 9.5
  • Phase: Single
  • Wire Size: 8 AWG
  • Water Connection: 3/8"
  • Water Connection Type: Compression
  • Color: White
